1102546 | SICK SENSORS | MM18-00A-N-VC0 Magnetic Sensors

₹ 10,504.83

₹ 8,902.40 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1102546

Original Equipment Manufacturer

SICK SENSORS

Description

Housing Metric
Thread size M18 x 1
Diameter Ø 18 mm
Sensing range Sn 5 mm ... 120 mm 1)
Safe sensing range Sa 97.2 mm
Magnetic sensitivity 0.4 mT
Switching frequency 1,000 Hz
Connection type Male connector M12, 4-pin
Switching output NAMUR
Switching output detail NAMUR
Output characteristic Control current depending on switching state according to NAMUR EN 60947-5-6
Electrical wiring DC 2-wire
Ripple ≤ 5 % 1)
Time delay before availability ≤ 2 ms
Hysteresis ≤ 25 %
Reproducibility ≤ 1 % 2)
Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2
Current consumption, sensor is activated ≥ 2.5 mA
Current consumption, sensor is not activated ≤ 1 mA
Cable resistance ≤ 50 Ω
Wire-break protection
Reverse polarity protection Yes
Short-circuit protection Yes
Shock and vibration resistance 30 g, 11 ms / 10 ... 55 Hz, 1 mm
Ambient operating temperature –25 °C ... +70 °C
Housing material Metal, Stainless steel V4A (1.4404, 316L)
Housing length 65 mm
