1086260 | SICK SENSORS | DBS60E-S4CK05000 Incremental Encoder

₹ 23,352.67

₹ 19,790.40 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1086260

Original Equipment Manufacturer

SICK SENSORS

Description
Communication interface Incremental
Communication Interface detail TTL / RS-422
Number of signal channels 6-channel
Initialization time < 5 ms 1)
Output frequency + 300 kHz 2)
Mechanical design Solid shaft, face mount flange
Shaft diameter 10 mm
With face
Shaft length 19 mm
Flange type / stator coupling Flange with 3 x M3 and 3 x M4
Weight + 0.3 kg 1)
Shaft material Stainless steel
Flange material Aluminum
Housing material Aluminum
Material, cable PVC
Start up torque + 1.2 Ncm (+20 °C)
Operating torque 1.1 Ncm (+20 °C)
Permissible shaft loading

100 N (radial) 2)

50 N (axial) 2)



SICK SENSORS 1086260 DBS60E-S4CK05000 Incremental Encoder
SICK SENSORS

1086260 | SICK SENSORS | DBS60E-S4CK05000 Incremental Encoder

₹ 19,790.40
Communication interface Incremental
Communication Interface detail TTL / RS-422
Number of signal channels 6-channel
Initialization time < 5 ms 1)
Output frequency + 300 kHz 2)
Mechanical design Solid shaft, face mount flange
Shaft diameter 10 mm
With face
Shaft length 19 mm
Flange type / stator coupling Flange with 3 x M3 and 3 x M4
Weight + 0.3 kg 1)
Shaft material Stainless steel
Flange material Aluminum
Housing material Aluminum
Material, cable PVC
Start up torque + 1.2 Ncm (+20 °C)
Operating torque 1.1 Ncm (+20 °C)
Permissible shaft loading

100 N (radial) 2)

50 N (axial) 2)
