1085705 | SICK SENSORS | GRTE18-P1162V Photoelectric Proximity Sensor

₹ 12,414.78

₹ 10,521.00 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Functional principle Photoelectric proximity sensor
Functional principle detail Energetic
Dimensions (W x H x D) 18 mm x 18 mm x 73.5 mm
Housing design (light emission) Cylindrical
Housing length 73.5 mm
Thread length 49.3 mm
Thread diameter (housing) M18 x 1
Optical axis Axial
Sensing range max. 5 mm ... 1,000 mm 1)
Sensing range 10 mm ... 800 mm 1)
Type of light Visible red light
Light source LED 2)
Light spot size (distance) Ø 45 mm (800 mm)
Wave length 650 nm
Weight 175 g
Housing material Metal, Stainless steel V4A (1.4404, 316L)
Optics material Plastic, PMMA
Tightening torque, max. 90 Nm
Enclosure rating

IP67

IP68 11)

IP69K 12)
Items supplied Fastening nuts (2 x)



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1085705

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Functional principle - Photoelectric proximity sensor

Functional principle detail - Energetic

Dimensions (W × H × D) - 18 mm × 18 mm × 73.5 mm

Housing design (light emission) - Cylindrical

Housing length - 73.5 mm

Thread length - 49.3 mm

Thread diameter (housing) - M18 × 1

Optical axis - Axial

Sensing range max. - 5 mm ... 1,000 mm

Sensing range - 10 mm ... 800 mm

Type of light - Visible red light

Light source - LED

Light spot size (distance) - Ø 45 mm (800 mm)

Wave length - 650 nm

Supply voltage UB - 10 V DC ... 30 V DC

Ripple - < 5 Vpp

Current consumption - 30 mA

Switching output - PNP

Output function - Complementary

Switching mode - Light/dark switching

Signal voltage PNP HIGH/LOW - VS - (≤ 3 V) / approx. 0 V

Output current Imax. - ≤ 100 mA

Response time - < 1,000 µs

Switching frequency - 500 Hz

Connection type - Cable, 4-wire, 2 m

Cable material - Plastic, PVC

Conductor cross section - 0.14 mm²

MTTFD - 1,408 years

DCavg - 0%

TM (mission time) - 20 years

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

ECOLAB certificate - ✔

cULus certificate - ✔

Photobiological safety (DIN EN 62471) certificate - ✔

ECLASS 5.1.4 - 27270902

ECLASS 6.0 - 27270902

ECLASS 7.0 - 27270902

ECLASS 8.0 - 27270902

ECLASS 9.0 - 27270902

ECLASS 10.0 - 27270902

ECLASS 11.0 - 27270902

ECLASS 12.0 - 27270902

ECLASS 13.0 - 27270902
