1069527 | SICK SENSORS | DFS60S-TDOC01024 Safety Encoder

₹ 65,253.06

₹ 55,299.20 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1069527

Original Equipment Manufacturer

SICK SENSORS

Description
Communication interface Incremental
Communication Interface detail Sin/Cos 1)
Initialization time 50 ms 2)
Output frequency ≤ 153.6 kHz
Power consumption ≤ 0.7 W (without load)
Mechanical design Through hollow shaft
Shaft diameter 10 mm
With feather key groove
Weight Approx. 0.25 kg 1)
Shaft material Stainless steel
Flange material Die-cast zinc
Housing material Aluminum die cast
Start up torque ≤ 0.8 Ncm (+20 °C)



SICK SENSORS 1069527 DFS60S-TDOC01024 SAFETY ENCODER
SICK SENSORS

1069527 | SICK SENSORS | DFS60S-TDOC01024 Safety Encoder

₹ 55,299.20
Communication interface Incremental
Communication Interface detail Sin/Cos 1)
Initialization time 50 ms 2)
Output frequency ≤ 153.6 kHz
Power consumption ≤ 0.7 W (without load)
Mechanical design Through hollow shaft
Shaft diameter 10 mm
With feather key groove
Weight Approx. 0.25 kg 1)
Shaft material Stainless steel
Flange material Die-cast zinc
Housing material Aluminum die cast
Start up torque ≤ 0.8 Ncm (+20 °C)
