1069123 | SICK SENSORS | GRTE18S-P246Z Photoelectric Proximity Sensor

₹ 4,433.85

₹ 3,757.50 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Functional principle Photoelectric proximity sensor
Functional principle detail Energetic
Dimensions (W x H x D) 18 mm x 18 mm x 38.1 mm
Housing design (light emission) Cylindrical
Thread diameter (housing) M18 x 1
Optical axis Axial, fully flush
Sensing range max. 5 mm ... 1,000 mm 1)
Sensing range 10 mm ... 800 mm 1)
Type of light Visible red light
Light source LED 2)
Light spot size (distance) Ø 45 mm (800 mm)
Wave length 650 nm
Housing material Metal, Nickel-plated brass and ABS
Optics material Plastic, PMMA
Enclosure rating IP67
Items supplied Fastening nuts (2 x)



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1069123

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Functional principle - Photoelectric proximity sensor

Functional principle detail - Energetic

Dimensions (W x H x D) - 18 mm × 18 mm × 38.1 mm

Housing design (light emission) - Cylindrical

Thread diameter (housing) - M18 × 1

Optical axis - Axial, fully flush

Sensing range max. - 5 mm … 1,000 mm¹

Sensing range - 10 mm … 800 mm¹

Type of light - Visible red light

Light source - LED²

Light spot size (distance) - Ø 45 mm (800 mm)

Wavelength - 650 nm

Adjustment - Potentiometer, 270°

Supply voltage UB - 10 V DC … 30 V DC¹

Ripple - < 5 Vpp²

Current consumption - 30 mA

Switching output - PNP

Output function - Complementary

Switching mode - Light/dark switching

Output current Imax. - ≤ 100 mA³

Response time - < 1,000 µs⁴

Switching frequency - 500 Hz⁵

Connection type - Male connector M12, 4-pin

Not applicable for this product

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

ECOLAB certificate - ✔

cULus certificate - ✔

Photobiological safety (DIN EN 62471) certificate - ✔

ECLASS 5.1.4 - 27270902

ECLASS 6.0 - 27270902

ECLASS 7.0 - 27270902

ECLASS 8.0 - 27270902

ECLASS 9.0 - 27270902

ECLASS 10.0 - 27270902

ECLASS 11.0 - 27270902

ECLASS 12.0 - 27270902

ECLASS 13.0 - 27270902
