SPARECRUX is NOT an authorized distributor for SICK SENSORS

1062202 | SICK SENSORS | KTM-MB31111P Contrast Sensors

₹ 24,473.84

₹ 20,740.54 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1062202

Original Equipment Manufacturer

SICK SENSORS

Description

Dimensions (W x H x D) 12 mm x 31.5 mm x 21 mm
Sensing distance ≤ 12.5 mm
Sensing distance tolerance ± 3 mm
Housing design Small
Light source LED, white 1)
Light emission Long side of housing
Light spot size Ø 2 mm (12.5 mm)
Light spot direction Round
Receiving filters None
Supply voltage 12 V DC ... 24 V DC 1)
Ripple ≤ 5 Vpp 2)
Current consumption < 50 mA 3)
Switching frequency 10 kHz 4)
Response time 50 µs 5)
Jitter 25 µs
Switching output PNP, NPN
Switching output (voltage) PNP: HIGH = UV ≤ 2 V / LOW approx. 0 V, NPN: HIGH = approx. U/ LOW ≤ 2 V
Switching mode Light/dark switching
Output current Imax. 50 mA 6)
