SPARECRUX is NOT an authorized distributor for SICK SENSORS

1050738 | SICK SENSORS | MPS-192TSTU0 Cylinder Sensors

₹ 36,060.80

₹ 30,560.00 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1050738

Original Equipment Manufacturer

SICK SENSORS

Description
Cylinder type T-slot
Supply voltage 15 V DC ... 30 V DC
Power consumption 22 mA, without load
Max. load resistance ≤ 500 Ω Power Output, at 24 V
Min. load resistance ≥ 2 kΩ 1)
Protection class III
Time delay before availability 1.5 s
Required magnetic field sensitivity, typ. 4 mT ... 30 mT
Resolution, typ. 0.03 % FSR (max. ≥ 0.05 mm) 2)
Linearity error, typ. 0.3 mm 3)
Repeat accuracy, typ. 0.06 % FSR (≥ 0.1 mm) 4)
Sampling rate, typ. 1 ms 5)
Reverse polarity protection Yes
Short-circuit protection Yes



SICK SENSORS 1050738 MPS-192TSTU0 Cylinder Sensors
SICK SENSORS

1050738 | SICK SENSORS | MPS-192TSTU0 Cylinder Sensors

₹ 30,560.00
Cylinder type T-slot
Supply voltage 15 V DC ... 30 V DC
Power consumption 22 mA, without load
Max. load resistance ≤ 500 Ω Power Output, at 24 V
Min. load resistance ≥ 2 kΩ 1)
Protection class III
Time delay before availability 1.5 s
Required magnetic field sensitivity, typ. 4 mT ... 30 mT
Resolution, typ. 0.03 % FSR (max. ≥ 0.05 mm) 2)
Linearity error, typ. 0.3 mm 3)
Repeat accuracy, typ. 0.06 % FSR (≥ 0.1 mm) 4)
Sampling rate, typ. 1 ms 5)
Reverse polarity protection Yes
Short-circuit protection Yes
