1047581 | SICK SENSORS | DT50-P1114 Laser Distance Sensor

₹ 36,300.58

₹ 30,763.20 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1047581

Original Equipment Manufacturer

SICK SENSORS

Description
Target Natural objects
Resolution 1 mm
Repeatability ≥ 2.5 mm 1) 2) 3)
Measurement accuracy ± 10 mm 4)
Response time 20 ms ... 30 ms, 20 ms / 30 ms 3) 5)
Output time ≥ 4 ms 6)
Light source Laser, red
visible red light
Type of light Visible red light
Laser class 2 (IEC 60825-1:2014, EN 60825-1:2014) 7)
Dimensions (W x H x D) 36.1 mm x 62.7 mm x 57.7 mm
Housing material Metal (zinc diecast)
Window material Plastic (PMMA)
Weight 200 g
Connection type Male connector, M12, 5-pin



SICK SENSORS 1047581 DT50-P1114 Laser Distance Sensor
SICK SENSORS

1047581 | SICK SENSORS | DT50-P1114 Laser Distance Sensor

₹ 30,763.20
Target Natural objects
Resolution 1 mm
Repeatability ≥ 2.5 mm 1) 2) 3)
Measurement accuracy ± 10 mm 4)
Response time 20 ms ... 30 ms, 20 ms / 30 ms 3) 5)
Output time ≥ 4 ms 6)
Light source Laser, red
visible red light
Type of light Visible red light
Laser class 2 (IEC 60825-1:2014, EN 60825-1:2014) 7)
Dimensions (W x H x D) 36.1 mm x 62.7 mm x 57.7 mm
Housing material Metal (zinc diecast)
Window material Plastic (PMMA)
Weight 200 g
Connection type Male connector, M12, 5-pin
