The SICK DT50-P1113 mid-range distance sensor is a reliable solution for precise distance measurement in industrial automation. With its advanced technology and robust design, it is ideal for applications requiring accurate and repeatable measurements over a wide range.
Key Features:
Measuring Range:
200 mm to 10,000 mm for objects with 90% remission factor.
200 mm to 6,500 mm for objects with 18% remission factor.
200 mm to 4,000 mm for objects with 6% remission factor.
Resolution: 1 mm for precise measurements.
Repeatability: ≥ 2.5 mm for consistent results.
Measurement Accuracy: ±10 mm.
Response Time: 20 ms to 30 ms for fast detection.
Light Source: Visible red laser (658 nm), Class 2 for safe operation.
Analog Output: 4 mA to 20 mA current output for flexible integration.
Digital Output: 1 x PNP output.
Supply Voltage: 10 V DC to 30 V DC.
Connection Type: M12, 5-pin male connector for easy installation.
Durable Housing: Zinc die-cast for robust industrial use.
Enclosure Rating: IP65 for protection against dust and water.
Operating Temperature Range: –30 °C to +65 °C for versatile applications.
Applications:
Perfect for precise distance measurement in material handling, logistics, packaging, and other industrial environments requiring accuracy and reliability over a wide range.
