1018945 | SICK SENSORS | WT24-2V540S10 Photoelectric Proximity Sensor

₹ 51,698.16

₹ 43,812.00 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Specification Details
Functional Principle Photoelectric proximity sensor
Functional Principle Detail Background suppression
Dimensions (W x H x D) 27 mm x 87.5 mm x 65 mm
Housing Design (Light Emission) Rectangular
Sensing Range Max. 100 mm ... 1,200 mm ¹
Sensing Range 100 mm ... 1,200 mm ¹
Type of Light Visible red light
Supply Voltage UB 10 V DC ... 30 V DC ¹
Ripple < 5 Vpp ²
Current Consumption 50 mA ³
Switching Output NPN, PNP
Switching Mode Light/dark switching



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1018945

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Functional principle - Photoelectric proximity sensor

Functional principle detail - Background suppression

Dimensions (W × H × D) - 27 mm × 87.5 mm × 65 mm

Housing design (light emission) - Rectangular

Sensing range max. - 100 mm ... 1,200 mm¹

Sensing range - 100 mm ... 1,200 mm¹

Type of light - Visible red light

Light source - LED²

Light spot size (distance) - Ø 40 mm (1,200 mm)

Adjustment - Potentiometer

Alarm output - ✔

Special features - Front lense made of glass

Supply voltage UB - 10 V DC ... 30 V DC¹

Ripple - < 5 Vpp²

Current consumption - 50 mA³

Switching output - NPN, PNP

Switching mode - Light/dark switching

Switching mode selector - Selectable via PNP/NPN selector, selectable via light/dark selector

Output current Imax. - ≤ 100 mA

Response time - ≤ 500 µs⁴

Switching frequency - 1,000 Hz⁵

Connection type - Plug, M12, 5-pin

MTTFD - 796 years

DCavg - 0 %

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

Photobiological safety (DIN EN 62471) certificate - ✔

ECLASS 5.1.4 - 27270902

ECLASS 6.0 - 27270902

ECLASS 7.0 - 27270902

ECLASS 8.0 - 27270902

ECLASS 9.0 - 27270902

ECLASS 10.0 - 27270902

ECLASS 11.0 - 27270902

ECLASS 12.0 - 27270902

ECLASS 13.0 - 27270902

ECLASS 14.0 - 27270902
