1018252 | SICK | WL12L-2B530
₹ 69,401.11
₹ 58,814.50 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
1018252 | SICK | WL12L-2B530
Manufacturer Part Number (MPN)
WL12L-2B530 (1018252)
Original Equipment Manufacturer
SICK SENSORS
Description
Description
The WL12L-2B530 is a small photoelectric retro-reflective sensor from SICK's W12-2 Laser series, optimized for detecting small objects and objects moving at high speeds. It employs a red laser light source for accurate detection over distances.
- Sensing Range: Up to 18 meters (with reflector PL80A)
- Light Source: Red laser diode
- Special Applications: Detecting small objects; high-speed object detection
- Output Type: PNP, light/dark switching
- Response Time: ≤ 0.5 ms
- Switching Frequency: 1,000 Hz
- Supply Voltage: 10 V DC to 30 V DC
- Connection Type: M12, 4-pin male connector
- Housing Material: Plastic
- Enclosure Rating: IP67
- Operating Temperature: –25 °C to +55 °C
- Dimensions: 49 mm x 15 mm x 41.5 mm
The WL12L-2B530 is suitable for applications such as high-speed packaging lines and small object detection.
