101193158 | SCHMERSAL | Safety Interlock Switch, BNS 36 Series

₹ 8,378.52

₹ 7,100.44 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

101193158

Original Equipment Manufacturer

SCHMERSAL

Description

Specification Details
Manufacturer Schmersal
Series BNS 36 Series
Model 101193158
Working Principle Magnetic drive
Contact Configuration SPST-NO / SPST-NC
Maximum Switching Voltage (DC) 75 V
Maximum Switching Current (DC) 400 mA
Degree of Protection IP67
Housing Material Glass-fibre reinforced thermoplastic
Mechanical Life 25 million cycles
Mounting Type Quasi-flush
Ambient Temperature -25°C to +70°C
Dimensions (L × W × H) 88 mm × 25 mm × 13 mm
Connector Type M8, 4-pole, latching interlocking
Features Magnetic actuation (no mechanical wear), Long service life,
Insensitive to misalignment and soiling, Tamper-proof coding,
Integral system diagnostics, Safety classification compliant with EN ISO 13849-1
