UCFL207D1 | NTN | Two Bolt Rhombus Flanged Unit, Cast Housing, Set Screw

₹ 1,838.44

₹ 1,558.00 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

UCFL207D1

Original Equipment Manufacturer

NTN

説明

Specification Details
Type 2-Bolt Rhombus Flanged Unit
Bearing Type Ball Bearing
Locking Device Set Screw
Seal Type Contact
Seal Material Nitrile Rubber
Bearing Number UC207D1
Housing Number FL207D1
Housing Material Cast Iron
Housing Construction 1 Piece
End Type Open
Performance Light Duty
Dynamic Load Rating 5778 lbf / 25.70 kN
Static Load Rating 3440 lbf / 15.30 kN
Maximum Rotational Speed 4200 RPM
Weight 1.164 lb / 0.530 kg
Operating Temperature Range -40 to 250 ºF / -40 to 120 ºC
Lubrication Relubricatable
