SPARECRUX is NOT an authorized distributor for RITTAL

SK 3244.110 | RITTAL | Toptherm Fan-And-Filter Units

₹ 42,172.02

₹ 35,739.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

SK 3244.110

Original Equipment Manufacturer

RITTAL

説明
Attribute Details
Product Type TopTherm Filter Fan Unit
Model / Article No. SK 3244.110 (3244110)
Mounting Wall-mounted, tool-free
Fan Technology Diagonal fan (1~ capacitor motor)
Air Throughput (Chopped-fibre Filter) 50 Hz: 700 m³/h (412 cfm) · 60 Hz: 770 m³/h (453.2 cfm)
Air Throughput (Pleated Filter) 50 Hz: 855 m³/h · 60 Hz: 905 m³/h
With Outlet Filter (1 × 3243200) 485/520 m³/h
With Outlet Filter (2 × 3243200) 570/630 m³/h
Rated Operating Voltage 115 V, 1~ (50/60 Hz)
Rated Power (Pel) 50 Hz: 100 W · 60 Hz: 145 W
Rated Current (max.) 50 Hz: 0.9 A · 60 Hz: 1.25 A
Dimensions (W × H) 323 mm × 323 mm
Installation Depth 130.5 mm
Mounting Cut-out (W × H) 292 mm × 292 mm
Protection Ratings IP 54 (standard), IP 55 (with pleated filter + absorber), IP 56 (with filter + hose-proof hood)
NEMA 12, 3, 3R, 4, 4X (with accessories)
Operating Temperature Range -30 °C … 55 °C
Storage Temperature Range -30 °C … 70 °C
Noise Level 50 Hz: 65 dB(A) · 60 Hz: 66 dB(A)
Service Life (L₁₀, 40 °C) 50 Hz: 66,000 h · 60 Hz: 62,000 h
Color RAL 7035 (Light Grey)
Supply Includes Complete unit, chopped-fibre filter mat
Safety Prefuse Miniature circuit-breaker/fuse: 6 A
Packaging Unit 1 piece
Weight (Net / Gross) 4.354 kg / 4.88 kg
Customs Tariff Number 84145915
EAN 4028177652187
ETIM Classification EC000320 (ETIM 8 & 9)
eCl@ss 8.0 27180716
Approvals CSA, KC Korea, UL + C-UL (FTTA), UR + C-UR (recognized)
