SPARECRUX is NOT an authorized distributor for PARKER

P2M2VCEE2CV00F8 | PARKER | Solenoid Valve 24 VDC

₹ 24,841.42

₹ 21,052.05 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

P2M2VCEE2CV00F8

Original Equipment Manufacturer

PARKER

説明

Type 3-way, 2-position dual valve
Operator Double solenoid
Voltage 24 VDC
Flow Coefficient (Cv) 0.44
Override Multi-function
Valve Type Manifold valve
Valve Passages 3-way
Valve Positions 2-position
Offset Return Type Spring return
Solenoid Connection Collective wiring
Supply Pressure Range Vacuum to 123 PSIG (Vacuum to 8.3 bar)
Operating Temperature 5°F to 140°F (-15°C to 60°C)
Port Size 6, 8, 10, 12 mm OD tube
Mounting Type Manifold
Material Nickel-plated brass
PARKER

P2M2VCEE2CV00F8 | PARKER | Solenoid Valve 24 VDC

₹ 21,052.05
Type 3-way, 2-position dual valve
Operator Double solenoid
Voltage 24 VDC
Flow Coefficient (Cv) 0.44
Override Multi-function
Valve Type Manifold valve
Valve Passages 3-way
Valve Positions 2-position
Offset Return Type Spring return
Solenoid Connection Collective wiring
Supply Pressure Range Vacuum to 123 PSIG (Vacuum to 8.3 bar)
Operating Temperature 5°F to 140°F (-15°C to 60°C)
Port Size 6, 8, 10, 12 mm OD tube
Mounting Type Manifold
Material Nickel-plated brass
