LX1D8N5 | SCHNEIDER ELECTRIC | TeSys D - contactor coil - LX1D8 - 415 V AC 50 Hz for 115 A contactor

₹ 494.99

₹ 419.48 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LX1D8N5

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

説明

Product Reference LX1D8N5
Brand / Range Schneider Electric – TeSys D
Product Type Contactor Coil
Control Circuit Voltage 415 V AC, 50 Hz
Compatible Contactor LC1D115
Average Resistance ~368 Ω at 20 °C
Inductance (closed) ~27.7 H
Coil Technology Without built-in suppressor
Drop-out Voltage 0.3–0.6 × Uc @ 55 °C
Operational Voltage 0.85–1.1 × Uc @ 55 °C
Inrush Power 300 VA (0.8 cos φ) @ 20 °C
Hold-in Power 22 VA (0.3 cos φ) @ 20 °C
Heat Dissipation 3–8 W @ 50 Hz
Mechanical Durability 8 million cycles
Maximum Operation Rate 2400 cycles/hour @ ≤ 60 °C
Operating Temperature –5 °C to +60 °C
Net Weight ≈ 0.26 kg
