LP-CC-2 | BUSSMANN | FUSE 600VAC 300VDC

₹ 3,923.50

₹ 3,325.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LP-CC-2

Original Equipment Manufacturer

BUSSMANN

説明
Specification Details
Product Name Eaton Bussmann series LP-CC fuse
Catalog Number LP-CC-2
UPC 051712180269
EAN 5027590063807
Product Length/Depth 1.5 in
Product Height 0.41 in
Product Width 0.41 in
Product Weight 0.015 lb
Warranty Not Applicable
Compliances CE Marked, RoHS Compliant
Certifications UL Listed, CSA Certified
Amperage Rating 2 A
Number of Elements Dual
Class Class CC
Interrupt Rating 20 kAIC at 300 VDC, 200 kAIC at 600 VAC
Fuse Indicator Non-indicating
Connection Ferrule end x ferrule end
Response Time 12 sec at 200%
Material Melamine tube
Packaging Type Standard
Quantity 10
Voltage Rating 600 VAC, 300 VDC
Type Current-limiting time-delay fuse
Special Features Rejection style
Application Specialized circuits and industrial control
