SPARECRUX is NOT an authorized distributor for BUSSMANN

C10G6 | BUSSMANN | 6AMP FUSE

₹ 1,612.00

₹ 1,366.10 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

C10G6

Original Equipment Manufacturer

BUSSMANN

説明

Specification Details
Product Name Eaton Bussmann Series Low Voltage Cylindrical Fuse
Catalog Number C10G6
Model Code CYLINDRICAL FUSE 10 x 38 6A GG 500V AC
UPC 051712754248
EAN 5027590493567
Product Length/Depth 38 mm
Product Height 10 mm
Product Width 10 mm
Product Weight 8.2 g
Warranty 1 year limited
Compliances CE Marked, GoST-R, RoHS Compliant
Certifications IEC 60269
Global Catalog C10G6
Amperage Rating 6 A
Fuse Size 10 x 38 mm
Current Type AC
Breaking Capacity 120 kA
Frequency Rating 45 Hz – 62 Hz
Rated Voltage AC 500 V
Class Class C gL/gG
Fuse Type C10G
Utilization Category gG (cable protection/equipment protection)
Fuse Indicator Other
Watt Losses 0.85 W
Connection Ferrule end x ferrule end
Construction Size 10 mm x 38 mm
Fuse Shape Cylindrical
Voltage Type AC
Suitable For CHM Modular fuse holder
Material Ceramic
Release Characteristic Other
Quantity 10
Voltage Rating 500 V
Type Fuse
Application For industrial applications, for general purpose use
BUSSMANN

C10G6 | BUSSMANN | 6AMP FUSE

₹ 1,366.10
Specification Details
Product Name Eaton Bussmann Series Low Voltage Cylindrical Fuse
Catalog Number C10G6
Model Code CYLINDRICAL FUSE 10 x 38 6A GG 500V AC
UPC 051712754248
EAN 5027590493567
Product Length/Depth 38 mm
Product Height 10 mm
Product Width 10 mm
Product Weight 8.2 g
Warranty 1 year limited
Compliances CE Marked, GoST-R, RoHS Compliant
Certifications IEC 60269
Global Catalog C10G6
Amperage Rating 6 A
Fuse Size 10 x 38 mm
Current Type AC
Breaking Capacity 120 kA
Frequency Rating 45 Hz – 62 Hz
Rated Voltage AC 500 V
Class Class C gL/gG
Fuse Type C10G
Utilization Category gG (cable protection/equipment protection)
Fuse Indicator Other
Watt Losses 0.85 W
Connection Ferrule end x ferrule end
Construction Size 10 mm x 38 mm
Fuse Shape Cylindrical
Voltage Type AC
Suitable For CHM Modular fuse holder
Material Ceramic
Release Characteristic Other
Quantity 10
Voltage Rating 500 V
Type Fuse
Application For industrial applications, for general purpose use
