A9N1P32C | SCHNEIDER ELECTRIC | Acti9 xC60 Miniature Circuit Breaker – 1 Pole 32 A C‑Curve 10 kA

₹ 2,557.96

₹ 2,167.76 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

A9N1P32C

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

説明

Product Title Acti9 xC60 Miniature Circuit Breaker – 1 Pole, 32 A, C‑Curve, 10 kA
Part Number A9N1P32C
Series / Range Acti9 xC60
Poles 1 Pole (1P)
Rated Current (In) 32 A
Trip Curve C‑Curve (suitable for general purpose loads)
Breaking Capacity (Icn) 10 kA @ 230/240 VAC (IEC 60898‑1)
Rated Operational Voltage (Ue) 230/240 VAC, 50/60 Hz
Rated Insulation Voltage (Ui) 420 VAC
Rated Impulse Withstand Voltage (Uimp) 4 kV
Mounting Mode Clip‑on 35 mm DIN rail or screw‑mount
Terminal Type Tunnel terminals for rigid/flexible conductors
Connection Cross-Section 1–25 mm² rigid or 1–16 mm² flexible
Tightening Torque 2 N·m
Mechanical Durability 20,000 operations
Electrical Durability 10,000 operations
Width / Pitch 18 mm (1 module)
Operating Temperature −25 °C to +60 °C
Protection Rating IP20 (front face, enclosed environment)
Standards & Certifications IEC 60898‑1, IEC 60947‑2; CE, RoHS, REACh
Environmental Profile Green Premium product
