SPARECRUX is NOT an authorized distributor for WAGO

750-479 | WAGO | 2-Ch Differential Analog Input, ±10 VD

₹ 15,694.00

₹ 13,300.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

750-479

Original Equipment Manufacturer

WAGO

説明
Specification D“2-Ch Differential Analog Input, ±10 VDetails
Number of Analog Inputs 2
Total Number of Channels (Module) 2
Signal Type Voltage
Signal Type (Voltage) -10 … +10 VDC
Sensor Connection 2 x (2-wire)
Input Filter Low pass (1st order), fG = 5 kHz
Connection Technology: I/O 6 x CAGE CLAMP®
Connectable Conductor Materials Copper
Connection Type Inputs/Outputs
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Mounting Type DIN-35 rail
Pluggable Connector Fixed
Color Light gray
Housing Material Polycarbonate; polyamide 6.6
Fire Load 0.815 MJ
Weight 49.6 g
Conformity Marking CE
