750-461 | WAGO | 2-Channel Analog Input for Pt100/RTD Sensors

₹ 72,578.97

₹ 61,507.60 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

750-461

Original Equipment Manufacturer

WAGO

説明
Specification Details
Number of Analog Inputs 2
Total Number of Channels (Module) 2
Signal Type Resistance Measurement
Sensor Connection 2 x (2-wire, 3-wire)
Data Width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Resolution (over entire range) 0.1 °C
Conversion Time (typ.) 320 ms
Measurement Error (reference temperature 25°C) 0.2% max deviation from upper-range value
Connection Technology: I/O 8 x CAGE CLAMP®
Connectable Conductor Materials Copper
Connection Type Inputs/Outputs
Solid Conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Fine-stranded Conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Strip Length 8 … 9 mm / 0.31 … 0.35 inches
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from Upper-edge of DIN-rail 62.6 mm / 2.465 inches
Mounting Type DIN-35 rail
Pluggable Connector Fixed
Color Light gray
Housing Material Polycarbonate; polyamide 6.6
Fire Load 0.815 MJ
Weight 50.7 g
Conformity Marking CE
