6068443 | SICK SENSORS | UM18-21212E211 Ultrasonic Distance Sensor

₹ 44,397.97

₹ 37,625.40 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Operating range, limiting range 65 mm ... 350 mm, 600 mm
Target Natural objects
Resolution ≥ 0.069 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2) 3)
Temperature compensation ✔
Response time 64 ms
Switching frequency 12 Hz
Output time 16 ms
Supply voltage UB DC 10 V ... 30 V 1)
Power consumption ≤ 1.2 W 2)
Initialization time < 300 ms
Display 2 x LED
Enclosure rating IP65 / IP67



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

6068443

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Operating range, limiting range - 65 mm ... 350 mm, 600 mm

Resolution - ≥ 0.069 mm

Repeatability - ± 0.15 % 1)

Measurement accuracy - ± 1 % 2) 3)

Temperature compensation - ✔

Response time - 64 ms

Switching frequency - 12 Hz

Output time - 16 ms

Ultrasonic frequency (typical) - 400 kHz

Supply voltage UB - DC 10 V ... 30 V 1)

Power consumption - ≤ 1.2 W 2)

Initialization time - < 300 ms

Display - 2 x LED

Enclosure rating - IP65 / IP67

Protection class - III

Dimensions (W x H x D) - 18 mm x 18 mm x 52.7 mm

Design - Cylindrical

Sending axis - Straight

Housing material - Metal (nickel-plated brass, ultrasonic transducer: polyurethane foam, glass epoxy resin)

Weight - 25 g

Thread size - M18 x 1

Connection type - Male connector, M12, 5-pin

Not applicable for this product

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

China Compulsory Product Certification (CCC) exempt - ✔

ECLASS 5.1.4 - 27270804

ECLASS 6.0 - 27270804

ECLASS 7.0 - 27270804

ECLASS 8.0 - 27270804

ECLASS 9.0 - 27270804

ECLASS 10.0 - 27270804

ECLASS 11.0 - 27270804
