6054715 | SICK SENSORS | UC30-215162 Ultrasonic Distance Sensor

₹ 48,339.05

₹ 40,965.30 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Operating range, limiting range 600 mm ... 6,000 mm, 8,000 mm
Target Natural objects
Resolution ≥ 0.18 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2) 3)
Temperature compensation ✔
Response time 240 ms
Switching frequency 3 Hz
Output time 60 ms
Supply voltage UB DC 9 V ... 30 V 1)
Power consumption ≤ 1.2 W 2)
Initialization time < 450 ms
Indication 2 x LED
Enclosure rating IP65 / IP67



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

6054715

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Operating range, limiting range - 600 mm ... 6,000 mm, 8,000 mm

Resolution - ≥ 0.18 mm

Repeatability - ± 0.15 % ¹)

Measurement accuracy - ± 1 % ²) ³)

Temperature compensation - ✔

Response time - 240 ms

Switching frequency - 3 Hz

Output time - 60 ms

Supply voltage UB - DC 9 V ... 30 V ¹)

Power consumption - ≤ 1.2 W ²)

Initialization time - < 450 ms

Display - 2 × LED

Enclosure rating - IP65 / IP67

Protection class - III

Dimensions (W × H × D) - 62 mm × 62 mm × 37.2 mm ¹) / 62 mm × 62 mm × 36.7 mm ²)

Design - Rectangular

Sending axis - Straight

Housing material - Plastic (PBT/PET, ultrasonic transducer: polyurethane foam, glass epoxy resin)

Weight - 240 g

Not applicable for this product

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

China Compulsory Product Certification (CCC) exempt - ✔

ECLASS 5.1.4 - 27270804

ECLASS 6.0 - 27270804

ECLASS 7.0 - 27270804

ECLASS 8.0 - 27270804

ECLASS 9.0 - 27270804

ECLASS 10.0 - 27270804

ECLASS 11.0 - 27270804

ECLASS 12.0 - 27272806
