551375 | FESTO | Proximity Sensor SMT-10M-PS-24V-E-0,3-L-M8D

₹ 2,256.68

₹ 1,912.44 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

551375

Original Equipment Manufacturer

FESTO

説明
Feature Specification
Design For C-slot
Standard Compliance EN 60947-5-2
Symbol 00991153
Approvals RCM, CE, UKCA, RoHS compliant
Special Characteristics Oil resistant
Materials RoHS-compliant, halogen-free
Measured Variable Position
Measuring Principle Magneto-resistive
Ambient Temperature Range -40 °C ... 70 °C
Repetition Accuracy 0.2 mm
Switching Output PNP
Switching Element Function Normally open (N/O) contact
Switch-on Time ≤ 1.3 ms
Switch-off Time 4.2 ms ... 7.3 ms
Max. Switching Frequency 130 Hz
Max. Output Current 100 mA
Max. Output Current (with mounting kits) 50 mA
Max. Switching Capacity DC 2.8 W
Max. Switching Capacity DC (with mounting kits) 1.5 W
Voltage Drop ≤ 1.7 V
Off-state Current < 0.05 mA
Short Circuit Current Rating Yes
Overload Protection Available
Rated Operational Voltage DC 24 V
Operational Voltage Range DC 5 V ... 30 V
Residual Ripple 10%
Reverse Polarity Protection For all electrical connections
Electrical Connection Type Cable with plug
Connector System M8x1, A-coded, EN 61076-2-104
Number of Connections/Cores 3
Type of Mounting Screw-type lock, rotatable
Compatible Mounting Types Rotatable/non-rotatable screw-type lock
Connection Outlet Orientation In-line
Material Electrical Contact Gold-plated brass
Material Connector Housing TPE-U (PU)
Material Screw-type Lock Nickel-plated brass
