SPARECRUX is NOT an authorized distributor for FESTO

This product has been discontinued, and manufacturer warranty or support may no longer be available.

541328 | FESTIO | Connecting Cable NEBU-M12G5-K-5-LE4

₹ 1,018.74

₹ 863.34 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

541328

Original Equipment Manufacturer

FESTO

説明

Specification Details
Manufacturer Part No. NEBU‑M12G5‑K‑5‑LE4
Also Known As 541328
Cable Type Sensor connecting cable, universal, open end
Connector (Field Device Side) M12×1 A‑coded socket, straight, 5‑pin (4 wires)
Connection (Controller Side) Open end, 4 wires
Cable Length 5 m (16.4 ft)
Protection Rating IP65 / IP68 / IP69K
Cable Material TPE‑U (PUR); gray sheath, black housing
Operating Voltage 0–250 V AC / DC
Current Rating 4 A at 40 °C
Surge Voltage Strength 2.5 kV
Temperature Range -25 °C … 70 °C (fixed), -5 °C … 70 °C (flex)
Bending Radius (Fixed) 14 mm
Bending Radius (Moving) 46 mm
Weight Approx. 140–145 g
Corrosion Resistance Class CRC 2 (moderate)
Special Features Oil‑resistant, with 2 label holders, RoHS‑compliant, halogen‑free
Standards Compliance EN 61076‑2‑101, EN 60947‑5‑2
