SPARECRUX is NOT an authorized distributor for FESTO

538028 | FESTO | Precision Pressure Regulator MS6-LRP

₹ 26,471.74

₹ 22,433.68 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

538028

Original Equipment Manufacturer

FESTO

説明
Parameter Specification
Size 6
Series MS
Actuator Lock Rotary knob with detent, integrated lock, or closable with accessories
Mounting Position Optional
Design Piloted precision diaphragm control valve / pressure regulator
Controller Function Output pressure constant with secondary venting
Symbol(s) 00991973, 00995303, 00995326
Prepared For G1/4 or G1/8 pressure gauge or display; pressure sensor; operational status indicator
Operating Pressure 0.1 MPa ... 1.4 MPa (1 ... 14 bar)
Pressure Regulation Range 0.05 bar ... 12 bar
Max. Pressure Hysteresis 0.02 bar ... 0.05 bar
Flow Rates Secondary exhaust: 220 ... 900 l/minNominal: 800 ... 9,000 l/min
Electrical Specs 24 V DC (21.6–26.4 V), 4.2 W max, 0.16 A max, 10% ripple
Analogue Control Input 0–10 V or 4–20 mA
Approvals & Certifications c UL us – Recognized, CE, UKCA, ATEX Zones 1/2/21/22 (Gas II 2G, Dust II 2D), EPL Db/Gb
Operating Media Compressed air (ISO 8573‑1:2010), inert gases, ester oil < 0.1 mg/m³ (ISO 8573‑1:2010)
Lubrication Not allowed
Corrosion Resistance (CRC) 2 – Moderate corrosion stress
PWIS Conformity VDMA24364‑B1/B2‑L
Temperature Range Media & ambient: −10 °C ... 60 °C
