SPARECRUX is NOT an authorized distributor for SICK SENSORS

5308056 | SICK SENSORS | LL3-TB03 Fiber-optic Sensors

₹ 7,246.14

₹ 6,140.80 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

5308056

Original Equipment Manufacturer

SICK SENSORS

説明

Device type Fiber-optic cables
Functional principle Through-beam system, consisting of a sender and a receiver
Fiber-optic head design Threaded sleeve, Long end sleeve, Bendable sleeve, 90° deflection
Application Standard
Compatible fiber-optic amplifiers WLL80, WLL180, GLL170(T), WLL24 Ex
Sensing range max. 3,600 mm (Sensing range of WLL80 at 8 ms)
Minimal object diameter 0.2 mm 1)
Light emission Axial
Thread diameter (housing) M4
Optical fiber taper diameter ≥ 1.5 mm
Optical fiber taper length after 2 mm ≥ 90 mm
Minimum bend radius of end sleeve 10 mm



SICK SENSORS 5308056 LL3-TB03 Fiber-optic Sensors
SICK SENSORS

5308056 | SICK SENSORS | LL3-TB03 Fiber-optic Sensors

₹ 6,140.80
Device type Fiber-optic cables
Functional principle Through-beam system, consisting of a sender and a receiver
Fiber-optic head design Threaded sleeve, Long end sleeve, Bendable sleeve, 90° deflection
Application Standard
Compatible fiber-optic amplifiers WLL80, WLL180, GLL170(T), WLL24 Ex
Sensing range max. 3,600 mm (Sensing range of WLL80 at 8 ms)
Minimal object diameter 0.2 mm 1)
Light emission Axial
Thread diameter (housing) M4
Optical fiber taper diameter ≥ 1.5 mm
Optical fiber taper length after 2 mm ≥ 90 mm
Minimum bend radius of end sleeve 10 mm
