529027 | FESTO | Pressure Sensor SDE5-D2-0-Q-6-P-M8

₹ 7,286.50

₹ 6,175.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

529027

Original Equipment Manufacturer

FESTO

説明
Category Specification
Approval RCM trademark, c UL us - Recognized (OL)
CE Mark To EU EMC Directive (see declaration of conformity)
RoHS Directive In accordance with EU RoHS Directive
UKCA Marking To UK instructions for EMC and UK RoHS instructions (see declaration of conformity)
Note on materials RoHS-compliant
Measured variable Differential pressure, Relative pressure
Measurement method Piezoresistive pressure sensor
Pressure measuring range start value -1 bar
Pressure measuring range end value 10 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible
Media temperature 0 °C ... 50 °C
Ambient temperature 0 °C ... 50 °C
Repetition accuracy ± 0.3 %FS
Temperature coefficient ± 0.05 %FS/K
Switching output NPN, PNP
Switching function Window comparator, Freely programmable, Threshold value with fixed hysteresis, Threshold value with variable hysteresis
Switching element function N/C contact, N/O contact, Switchable
Max. output current 100 mA
Analogue output 0 - 10 V
Output characteristic curve start value 0 V
Output characteristic curve end value 10 V
Accuracy analogue output ± 3 %FS
