SPARECRUX is NOT an authorized distributor for LEUZE ELECTRONIC

50106548 | LEUZE ELECTRONIC | Photoelectric Sensor

₹ 23,541.00

₹ 19,950.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

50106548

Original Equipment Manufacturer

LEUZE ELECTRONIC

説明
Specification Details
Series 46B
Operating Principle Diffuse reflection principle with background suppression
Operating Range (White 90%) 0 … 2.5 m
Operating Range (Gray 18%) 0.005 … 1.8 m
Operating Range (Black 6%) 0.01 … 1.2 m
Operating Range Limit 0 … 2.5 m (Typical operating range)
Beam Path Divergent
Light Source Infrared LED
Wavelength 850 nm
Transmitted-Signal Shape Pulsed
LED Group 1
Light Spot Geometry Rectangular
Protective Circuits Polarity reversal protection, Short-circuit protected
Supply Voltage (UB) 10 … 30 V DC
Current Consumption (max.) 30 mA
Residual Ripple 0 … 15 % of UB
Open-Circuit Current 0 … 30 mA
Number of Digital Switching Outputs 2
Output Type Digital switching output
Switching Element Transistor, Push-pull
Switching Principle Light switching (PNP) / Dark switching (NPN)
Switching Frequency 200 Hz
Response Time 2.5 ms
Readiness Delay 100 ms
