408760 | LEGRAND | AC:415V DX3 MCB

₹ 1,524.04

₹ 1,291.56 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

408760

Original Equipment Manufacturer

LEGRAND

説明

Specification Details
Brand Legrand
Model Number 408760
Product Type Miniature Circuit Breaker (MCB)
Number of Poles 3 Pole (TP)
Rated Current 10 Amps
Rated Voltage 415V AC
Breaking Capacity 10 kA
Tripping Curve C
Mounting Type DIN Rail
Protection Class IP20
Ambient Temperature Range -25°C to +70°C
Frequency 50/60 Hz
Conductor Cross Section (Solid-Core) 1.5–35 mm²
Conductor Cross Section (Multi-Wired) 1.5–25 mm²
Width 53.4 mm
Height 94.8 mm
Depth 77.8 mm
Degree of Impact Strength (IK) IK02
Storage Temperature -40°C to +70°C
Electric Supply Direction Top or Bottom
Color Grey
RAL Number 7035
Halogen-Free Yes
Connection Type Screwed Terminal
Label Space/Information Surface Yes
