3628 | FESTO | Toggle Lever Valve With Idle Return L-3-M5

₹ 1,190.68

₹ 1,009.05 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

Original Equipment Manufacturer

FESTO

説明

Feature Specification
Valve Function 3/2-way, closed, monostable
Type of Actuation Mechanical
Standard Nominal Flow Rate 80 l/min (DIN 1343)
Pneumatic Working Port M5
Operating Pressure -0.95 bar to 8 bar
Design Poppet seat
Nominal Size 2 mm
Type of Piloting Direct
Symbol 00991096
Operating Medium Compressed air (ISO 8573-1:2010 [-:-:-])
Note on Medium Lubricated operation possible (lubrication then always required)
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Ambient Temperature Range -10 °C to 60 °C
Actuating Force 16.5 N
Product Weight 43 g
Mounting Type With through-hole
Pneumatic Connection – Port 1 M5
Pneumatic Connection – Port 2 M5
Material – Seals NBR (Nitrile Butadiene Rubber)
Material – Housing Die-cast zinc
