SPARECRUX is NOT an authorized distributor for ABB

2CSJ201001R0001 | ABB | Residual Current Monitor

₹ 66,084.67

₹ 56,003.96 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

2CSJ201001R0001

Original Equipment Manufacturer

ABB

説明
Parameter Details
Brand ABB
Model Number RD3-48 (2CSJ201001R0001)
Product Type Residual Current Monitor (Earth Leakage Relay)
Type of Residual Current Type A (for mixed systems)
Rated Voltage (Ur) 48 V AC/DC
Rated Control Supply Voltage (Us) 48 V AC/DC (50/60 Hz)
Current Rating Adjustable response value: 30–500 mA
Delay Time (τ) Adjustable from 0 to 10 seconds
Number of Contacts 2 (1 Normally Open)
Mounting Type DIN Rail
Power Loss 0.6 W
Width 52.8 mm
Height 85 mm
Depth 65 mm
Weight 0.223 kg
Compliance IEC EN 60947-2 Annex M
RoHS Compliant Yes
Country of Origin Italy
