SPARECRUX is NOT an authorized distributor for ABB

1SFL487062R1222 | ABB | AF190B-30-22RT-12 Contactor

₹ 61,655.00

₹ 52,250.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1SFL487062R1222

Original Equipment Manufacturer

ABB

説明
Feature Specification
Product Type 3‑pole AC power contactor with auxiliary contacts
Main Contacts (NO / NC) 3 NO / 0 NC
Auxiliary Contacts (NO / NC) 2 NO + 2 NC
Rated Operational Voltage (Main Circuit) Up to 1000 V (IEC) / 600 V (UL)
Rated Current, AC‑1 ~250 A (at 1000 V, 40 °C)
Rated Current, AC‑3 ~190 A (at 400‑415 V)
Rated Motor Power, AC‑3 (400 V) 90 kW
Control (Coil) Voltage Range 48‑130 V AC/DC
Standards / Certifications IEC/EN 60947‑1 & 60947‑4‑1, UL/CSA equivalents; RoHS
Ambient / Mechanical Durability High switching endurance; mechanical life (~5 million operations); able to handle surges in unstable supply networks
ABB

1SFL487062R1222 | ABB | AF190B-30-22RT-12 Contactor

₹ 52,250.00
Feature Specification
Product Type 3‑pole AC power contactor with auxiliary contacts
Main Contacts (NO / NC) 3 NO / 0 NC
Auxiliary Contacts (NO / NC) 2 NO + 2 NC
Rated Operational Voltage (Main Circuit) Up to 1000 V (IEC) / 600 V (UL)
Rated Current, AC‑1 ~250 A (at 1000 V, 40 °C)
Rated Current, AC‑3 ~190 A (at 400‑415 V)
Rated Motor Power, AC‑3 (400 V) 90 kW
Control (Coil) Voltage Range 48‑130 V AC/DC
Standards / Certifications IEC/EN 60947‑1 & 60947‑4‑1, UL/CSA equivalents; RoHS
Ambient / Mechanical Durability High switching endurance; mechanical life (~5 million operations); able to handle surges in unstable supply networks
