SPARECRUX is NOT an authorized distributor for ALLEN BRADLEY

1738-ADN18 | ALLEN BRADLEY | ArmorPoint I/O DeviceNet Adapter with 18mm Connectors

₹ 42,715.24

₹ 36,199.36 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1738-ADN18

Original Equipment Manufacturer

ALLEN BRADLEY

説明

Catalog Number 1738-ADN18
Module Type ArmorPoint DeviceNet Network Adapter
Communication Interface DeviceNet
Connector Type Mini Connector - Drop
Input Voltage Range 10–28V DC
Field Side Power Requirements 24V DC (+20% = 28.8V DC) @ 400mA (8.0W)
Power Consumption 8.0W at 24V
Inrush Current 6A for 10ms
Power Dissipation 2.8W at 28.8V
Operating Temperature Range -20°C to 60°C
Storage Temperature Range -40°C to 85°C
Relative Humidity 5% to 95% non-condensing
Vibration 5 g @ 10...500 Hz
Shock 30 g operational, 50 g non-operational
Certifications CE, UL, cUL, ATEX
ALLEN BRADLEY

1738-ADN18 | ALLEN BRADLEY | ArmorPoint I/O DeviceNet Adapter with 18mm Connectors

₹ 36,199.36
Catalog Number 1738-ADN18
Module Type ArmorPoint DeviceNet Network Adapter
Communication Interface DeviceNet
Connector Type Mini Connector - Drop
Input Voltage Range 10–28V DC
Field Side Power Requirements 24V DC (+20% = 28.8V DC) @ 400mA (8.0W)
Power Consumption 8.0W at 24V
Inrush Current 6A for 10ms
Power Dissipation 2.8W at 28.8V
Operating Temperature Range -20°C to 60°C
Storage Temperature Range -40°C to 85°C
Relative Humidity 5% to 95% non-condensing
Vibration 5 g @ 10...500 Hz
Shock 30 g operational, 50 g non-operational
Certifications CE, UL, cUL, ATEX
