SPARECRUX is NOT an authorized distributor for FESTO

170857 | FESTO | Guided Drive DFM-32-40-P-A-GF

₹ 12,395.70

₹ 10,504.83 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

170857

Original Equipment Manufacturer

FESTO

説明
Specification Details
Distance from Centre of Gravity of Load to Yoke Plate (xs) 50 mm
Stroke 40 mm
Piston Diameter 32 mm
Operating Mode, Drive Unit Yoke
Cushioning Elastic cushioning rings/plates at both ends
Mounting Position Optional
Guide Plain-bearing guide
Design Guidance
Position Detection Via proximity switch
Symbol 00991737
Operating Pressure 0.15 MPa ... 1 MPa / 1.5 bar ... 10 bar
Max. Speed 0.8 m/s
Mode of Operation Double-acting
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on Operating and Pilot Medium Lubricated operation possible (lubricated operation always required thereafter)
Corrosion Resistance Class (CRC) 1 - Low corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Cleanroom Class Class 6 according to ISO 14644-1
Ambient Temperature -20 °C ... 80 °C
Impact Energy in End Positions 0.4 J
Max. Force Fy 1227 N
Max. Force Fy (Static) 1227 N
Max. Force Fz 1227 N
Max. Force Fz (Static) 1227 N
Max. Moment Mx 47.84 Nm
Max. Torque Mx (Static) 47.84 Nm
Max. Moment My 24.53 Nm
Max. Torque My (Static) 24.53 Nm
Max. Moment Mz 24.53 Nm
Max. Torque Mz (Static) 24.53 Nm
Max. Permissible Torque Load Mx (as a Function of Stroke) 8.6 Nm
Max. Effective Load (Dependent Upon Stroke at Defined Distance xs) 161 N
Theoretical Force at 0.6 MPa (Return Stroke) 415 N
Theoretical Force at 0.6 MPa (Advance Stroke) 482 N
