SPARECRUX is NOT an authorized distributor for FESTO

161246 | FESTO | Flat Cylinder DZF-25- -A-P-A

₹ 4,325.62

₹ 3,665.78 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

161246

Original Equipment Manufacturer

FESTO

説明
Parameter Value
Stroke 1 mm ... 200 mm
Piston diameter 25 mm
Equivalent diameter —
Piston rod thread M10x1.25
Torsional backlash at piston rod ± 1°
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Design Piston, Piston rod
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Protection against torque / guide Oval piston
Operating pressure 0.1 MPa ... 1 MPa1 bar ... 10 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (then always required)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.1 J
Max. torque for protection against torsion 0.5 Nm
Theoretical force at 0.6 MPa (return stroke) 247 N
Theoretical force at 0.6 MPa (advance stroke) 295 N
