156621 | FESTO | Compact Cylinder ADVU-32-30-A-P-A

₹ 6,291.55

₹ 5,331.82 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

156621

Original Equipment Manufacturer

FESTO

説明
Feature Specification
Stroke 30 mm
Piston diameter 32 mm
Piston rod thread M10x1.25
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Piston-rod end Male thread
Design Piston
Components Piston rod
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Operating pressure 0.08 MPa ... 1 MPa / 0.8 bar ... 10 bar / 11.6 psi ... 145 psi
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (required if used)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.4 J
Theoretical force at 0.6 MPa (6 bar, 87 psi) return stroke 415 N
Theoretical force at 0.6 MPa (6 bar, 87 psi) advance stroke 483 N
Moving mass for 0 mm stroke 49 g
Additional moving mass per 10 mm stroke 9 g
Basic weight for 0 mm stroke 300 g
Additional weight per 10 mm stroke 40 g
Type of mounting With through-hole
With accessories Yes
Pneumatic connection G1/8
Material collar screws Galvanised steel
Material cover Wrought aluminium alloy
Material dynamic seals NBR, TPE-U (PU)
Material piston rod High-alloy stainless steel
Material cylinder barrel Wrought aluminium alloy
