151215 | FESTO | One-way Flow Control Valve GR-1/8-B

₹ 835.56

₹ 708.10 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

151215

Original Equipment Manufacturer

FESTO

説明
Property Value
Valve function One-way flow control function
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Adjustment component Knurled screw
Type of mounting With through-hole
Standard nominal flow rate in flow control direction 210 l/min
Standard nominal flow rate in blocked direction 180 l/min ... 275 l/min
Operating pressure 0.5 bar ... 10 bar
Ambient temperature -20 °C ... 60 °C
Material housing Wrought aluminium alloy
Explosion protection See certificate for details (Zones 1, 2, 21, 22 ATEX)
Mounting position Optional
Symbol 00991453
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation required if used)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -20 °C ... 60 °C
Nominal size 3 mm
Product weight 31 g
Note on materials RoHS-compliant
Material seals NBR
Material sleeve POM
Material adjusting screw High-alloy steel
Material nut Wrought aluminium alloy
FESTO

151215 | FESTO | One-way Flow Control Valve GR-1/8-B

₹ 708.10
Property Value
Valve function One-way flow control function
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Adjustment component Knurled screw
Type of mounting With through-hole
Standard nominal flow rate in flow control direction 210 l/min
Standard nominal flow rate in blocked direction 180 l/min ... 275 l/min
Operating pressure 0.5 bar ... 10 bar
Ambient temperature -20 °C ... 60 °C
Material housing Wrought aluminium alloy
Explosion protection See certificate for details (Zones 1, 2, 21, 22 ATEX)
Mounting position Optional
Symbol 00991453
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation required if used)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -20 °C ... 60 °C
Nominal size 3 mm
Product weight 31 g
Note on materials RoHS-compliant
Material seals NBR
Material sleeve POM
Material adjusting screw High-alloy steel
Material nut Wrought aluminium alloy
