SPARECRUX is NOT an authorized distributor for FESTO

1310166 | FESTO | Radial Gripper DHRS-40-A

₹ 49,205.29

₹ 41,699.40 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1310166

Original Equipment Manufacturer

FESTO

説明
Parameter Specification
Size 40
Max. replacement accuracy ≤ 0.2 mm
Max. opening angle 180°
Rotational symmetry tolerance ≤ 0.2 mm
Repetition accuracy (gripper) ≤ 0.1 mm
Number of gripper jaws 2
Mounting position Optional
Mode of operation Double-acting
Gripper function Radial
Design Force pilot operated motion sequence
Position detection Via proximity switch
Symbol 00991894
Operating pressure 2 bar – 8 bar
Max. operating frequency ≤ 2 Hz
Min. opening time at 0.6 MPa (6 bar, 87 psi) 113 ms
Min. closing time at 0.6 MPa (6 bar, 87 psi) 142 ms
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Lubrication note Lubricated operation possible (then permanently required)
Corrosion resistance class (CRC) 1 – Low corrosion stress
LABS (PWIS) conformity VDMA24364-B2-L
Suitability for Li-ion battery production Copper >1% by mass excluded (with exceptions for PCBs, cables, connectors, coils)
Ambient temperature range 5 °C – 60 °C
Gripping torque (opening) at 0.6 MPa 725 N·cm
Gripping torque (closing) at 0.6 MPa 660 N·cm
Mass moment of inertia 4.18 kg·cm²
Max. static force on gripper jaw (Fz) 200 N
Max. static torque at gripper (Mx) 14 Nm
Max. static torque at gripper (My) 14 Nm
Max. static torque at gripper (Mz) 14 Nm
Product weight 829 g
Type of mounting Via through-hole and centring sleeve
Pneumatic connection G1/8
Material note RoHS-compliant
Material (cover cap) PA (Polyamide)
Material (housing) Hard anodised wrought aluminium alloy
Material (gripper jaws) High-alloy steel
