1214282 | SICK SENSORS | SGS4-F108P3PS1T00 Automation Light Grid

₹ 60,814.37

₹ 51,537.60 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1214282

Original Equipment Manufacturer

SICK SENSORS

説明

Specification Details
Sensor principle Sender/receiver
Minimum detectable object (MDO) Parallel beam, 45 mm
Beam separation 40 mm
Optical light exit Flat
Number of beams 28
Detection height 1,080 mm
Parameterization Teach-in button
Cross beam/parallel beam Parallel beam active
Light source Infrared light
Wave length 950 nm
Supply voltage Vs DC24 V, ± 20 %
Power consumption receiver ≤ 70 mA
Ripple < 5 Vpp
Output current Imax. 100 mA



SICK SENSORS 1214282 SGS4-F108P3PS1T00 Automation Light Grid
SICK SENSORS

1214282 | SICK SENSORS | SGS4-F108P3PS1T00 Automation Light Grid

₹ 51,537.60
Specification Details
Sensor principle Sender/receiver
Minimum detectable object (MDO) Parallel beam, 45 mm
Beam separation 40 mm
Optical light exit Flat
Number of beams 28
Detection height 1,080 mm
Parameterization Teach-in button
Cross beam/parallel beam Parallel beam active
Light source Infrared light
Wave length 950 nm
Supply voltage Vs DC24 V, ± 20 %
Power consumption receiver ≤ 70 mA
Ripple < 5 Vpp
Output current Imax. 100 mA
