1109747 | SICK SENSORS | KTM-LP22182P Contrast Sensors

₹ 29,212.08

₹ 24,756.00 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1109747

Original Equipment Manufacturer

SICK SENSORS

説明
Dimensions (W x H x D) 12 mm x 31.5 mm x 21 mm
Sensing distance ≤ 50 mm
Sensing distance tolerance ± 30 mm
Housing design Small
Light source Laser, red 1)
Laser class I
Wave length 680 nm
Light emission Long side of housing
Light spot size Ø 1.7 mm (50 mm)
Light spot direction Round
Receiving filters None
Max. web speed 10 m/s 2)
Supply voltage 10 V DC ... 30 V DC
Ripple ≤ 5 Vpp 1)
Current consumption < 35 mA 2)
Switching frequency 4 kHz 3)
Response time 125 µs 4)
Jitter 57 µs
Accuracy 0.08 mm
Switching output PNP
