SPARECRUX is NOT an authorized distributor for SICK SENSORS

1081387 | SICK SENSORS | KTS-WB9214115UZZZZ Contrast Sensor

₹ 47,984.46

₹ 40,664.80 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1081387

Original Equipment Manufacturer

SICK SENSORS

説明

Special applications Standard
Device type Standard
Dimensions (W x H x D) 26 mm x 62 mm x 47.5 mm
Sensing distance ≤ 13 mm
Sensing distance tolerance ± 5 mm
Housing design Middle
Light source LED, RGB 1)
Wave length 470 nm, 525 nm, 625 nm
Supply voltage 10.8 V DC ... 28.8 V DC 1)
Ripple ≤ 5 Vpp 2)
Current consumption < 100 mA 3)
Switching frequency

50 kHz 4)

 5)

Response time

10 µs 6)

 7)

Jitter 5 µs 8)
Switching output Push-pull: PNP/NPN
Switching output (voltage) Push-pull: PNP/NPN HIGH = U- 3 V/LOW ≤ 3 V



SICK SENSORS 1081387 KTS-WB9214115UZZZZ Contrast Sensor
SICK SENSORS

1081387 | SICK SENSORS | KTS-WB9214115UZZZZ Contrast Sensor

₹ 40,664.80
Special applications Standard
Device type Standard
Dimensions (W x H x D) 26 mm x 62 mm x 47.5 mm
Sensing distance ≤ 13 mm
Sensing distance tolerance ± 5 mm
Housing design Middle
Light source LED, RGB 1)
Wave length 470 nm, 525 nm, 625 nm
Supply voltage 10.8 V DC ... 28.8 V DC 1)
Ripple ≤ 5 Vpp 2)
Current consumption < 100 mA 3)
Switching frequency

50 kHz 4)

 5)

Response time

10 µs 6)

 7)

Jitter 5 µs 8)
Switching output Push-pull: PNP/NPN
Switching output (voltage) Push-pull: PNP/NPN HIGH = U- 3 V/LOW ≤ 3 V
