1077099 | SICK SENSORS | WL2SG-2F1235 Photoelectric Retro Reflective Sensor

₹ 22,608.80

₹ 19,160.00 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Specification Details
Functional principle Photoelectric retro-reflective sensor
Functional principle detail Without reflector minimum distance (autocollimation/coaxial optics)
Dimensions (W x H x D) 7.7 mm x 21.8 mm x 13.5 mm
Housing design (light emission) Rectangular
Sensing range max. 0 m … 1.2 m¹
Sensing range 0 m … 0.55 m¹
Type of light Visible red light
Light source PinPoint LED²
Supply voltage UB 10 V DC … 30 V DC¹
Ripple < 5 Vpp²
Current consumption 20 mA³
Switching output PNP
Switching mode Dark switching



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1077099

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Functional principle – Photoelectric retro-reflective sensor

Functional principle detail – Without reflector minimum distance (autocollimation/coaxial optics)

Dimensions (W x H x D) – 7.7 mm x 21.8 mm x 13.5 mm

Housing design (light emission) – Rectangular

Sensing range max. – 0 m ... 1.2 m 1)

Sensing range – 0 m ... 0.55 m 1)

Type of light – Visible red light

Light source – PinPoint LED 2)

Light spot size (distance) – Ø 12 mm (250 mm)

Wave length – 640 nm

Adjustment – Cable

AutoAdapt – ✔

Special applications – Detecting transparent objects

Supply voltage UB – 10 V DC ... 30 V DC 1)

Ripple – < 5 Vpp 2)

Current consumption – 20 mA 3)

Switching output – PNP

Switching mode – Dark switching

Output current Imax. – ≤ 50 mA

Response time – < 0.5 ms 4)

Switching frequency – 1,000 Hz 5)

Connection type – Cable, 4-wire, 5 m 6)

Cable material – Plastic, PVC

Conductor cross section – 0.09 mm²

Cable diameter – Ø 3 mm

MTTFD – 1,987 years

DCavg – 0 %

EU declaration of conformity – ✔

UK declaration of conformity – ✔

ACMA declaration of conformity – ✔

Moroccan declaration of conformity – ✔

China RoHS – ✔

cULus certificate – ✔

Photobiological safety (DIN EN 62471) certificate – ✔

ECLASS 5.0 – 27270902

ECLASS 5.1.4 – 27270902

ECLASS 6.0 – 27270902

ECLASS 6.2 – 27270902

ECLASS 7.0 – 27270902

ECLASS 8.0 – 27270902

ECLASS 8.1 – 27270902
