1066111 | SICK SENSORS | WTB2S-2P3251 Photoelectric Proximity Sensor

₹ 18,639.16

₹ 15,795.90 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Functional principle Photoelectric proximity sensor
Functional principle detail Background suppression
Dimensions (W x H x D) 7.7 mm x 27.5 mm x 13.5 mm
Housing design (light emission) Rectangular
Sensing range max. 1 mm ... 150 mm 1)
Sensing range 18 mm ... 110 mm 1)
Type of light Visible red light



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1066111

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Functional principle – Photoelectric proximity sensor

Functional principle detail – Background suppression

Dimensions (W x H x D) – 7.7 mm x 27.5 mm x 13.5 mm

Housing design (light emission) – Rectangular

Sensing range max. – 1 mm ... 150 mm 1)

Sensing range – 18 mm ... 110 mm 1)

Type of light – Visible red light

Light source – PinPoint LED 2)

Light spot size (distance) – Ø 3.5 mm (50 mm)

Wave length – 640 nm

Adjustment – Potentiometer, 3 turns

Special applications – Detecting small objects

Supply voltage UB – 10 V DC ... 30 V DC 1)

Ripple – < 5 Vpp 2)

Current consumption – 20 mA 3)

Switching output – PNP

Switching mode – Light/dark switching

Output current Imax. – ≤ 50 mA

Response time – < 0.5 ms 4)

Switching frequency – 1,000 Hz 5)

Connection type – Cable with M8 male connector, 4-pin, 200 mm 6)

Cable material – Plastic, PVC

Conductor cross section – 0.09 mm²

Cable diameter – Ø 3 mm

MTTFD – 3,138 years

DCavg – 0 %

EU declaration of conformity – ✔

UK declaration of conformity – ✔

ACMA declaration of conformity – ✔

Moroccan declaration of conformity – ✔

China RoHS – ✔

cULus certificate – ✔

Photobiological safety (DIN EN 62471) certificate – ✔

ECLASS 5.0 – 27270904

ECLASS 5.1.4 – 27270904

ECLASS 6.0 – 27270904

ECLASS 6.2 – 27270904

ECLASS 7.0 – 27270904

ECLASS 8.0 – 27270904

ECLASS 8.1 – 27270904

ECLASS 9.0 – 27270904
