1062522 | SICK SENSORS | MPS-224TLTQ0 Cylinder Sensors

₹ 43,469.31

₹ 36,838.40 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1062522

Original Equipment Manufacturer

SICK SENSORS

説明

Measuring range 224 mm 1)
Housing length 237 mm
Output function IO-Link
Electrical wiring DC 4-wire
Supply voltage 15 V DC ... 30 V DC
Power consumption 25 mA, without load
Protection class III
Time delay before availability 1.5 s
Required magnetic field sensitivity, typ. 4 mT ... 30 mT
Resolution, typ. 0.03 % FSR (max. ≥ 0.05 mm) 1)
Linearity error, typ. 0.3 mm 2)
Repeat accuracy, typ. 0.06 % FSR (≥ 0.1 mm) 3)
Sampling rate, typ. 1 ms 4)
Reverse polarity protection Yes
Short-circuit protection Yes
Status indicator LED Yes
