1057656 | SICK SENSORS | DS35-B15821 Laser Distance Sensor

₹ 37,006.45

₹ 31,361.40 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Target Natural objects
Resolution 0.1 mm
Repeatability ≥ 0.5 mm 2) 3)
Measurement accuracy Typ. ± 10 mm 4)
Response time 2.5 ms ... 96.5 ms, 2.5 ms / 6.5 ms / 12.5 ms / 24.5 ms / 96.5 ms 5) 6)
Switching frequency 333 Hz / 100 Hz / 50 Hz / 25 Hz / 6 Hz 5) 6)
Output time 1 ms ... 32 ms, 1 ms/2 ms/4 ms/8 ms/32 ms 5) 7)
Light source Laser, infrared 8)
Infrared light
Type of light Infrared light
Laser class 1 (IEC 60825-1:2014, EN 60825-1:2014)
Supply voltage UB DC 12 V ... 30 V 1) 2)
Power consumption ≤ 1.7 W 3)
Ripple ≤ 5 Vpp 4)
Initialization time ≤ 500 ms
Warm-up time ≤ 20 min
Indication LEDs
Enclosure rating

IP65

IP67



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1057656

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Target - Natural objects

Resolution - 100 µm

Repeatability - ≥ 0.5 mm

Measurement accuracy - Typical ± 10 mm

Response time - 2.5 ms to 96.5 ms (2.5 ms / 6.5 ms / 12.5 ms / 24.5 ms / 96.5 ms)

Switching frequency - 333 Hz / 100 Hz / 50 Hz / 25 Hz / 6 Hz

Output time - 1 ms to 32 ms (1 ms / 2 ms / 4 ms / 8 ms / 32 ms)

Light source - Infrared laser

Type of light - Infrared light

Typical light spot size (distance) - 15 mm × 15 mm (at 2 m)

Normative reference - IEC 60825-1:2014, EN 60825-1:2014

Laser class - Class 1

Average laser service life (at 25 °C) - 100,000 hours

Supply voltage (UB) - DC 12 V to 30 V

Power consumption - ≤ 1.7 W

Ripple - ≤ 5 Vpp

Initialization time - ≤ 500 ms

Warm-up time - ≤ 20 min

Display - LEDs

Enclosure rating - IP65, IP67

Dimensions (W × H × D) - 32 mm × 58.67 mm × 42.7 mm

Housing material - Plastic (ABS/PC)

Window material - Plastic (PMMA)

Weight - 65 g

Not applicable for this product

EU Declaration of Conformity - Yes

UK Declaration of Conformity - Yes

ACMA Declaration of Conformity - Yes

Moroccan Declaration of Conformity - Yes

China RoHS - Yes

cTUVus Certificate - Yes

Information according to Art. 3 of Data Act (Regulation EU 2023/2854) - Yes

ECLASS 5.1.4 - 27270801

ECLASS 6.0 - 27270801

ECLASS 7.0 - 27270801

ECLASS 8.0 - 27270801

ECLASS 9.0 - 27270801

ECLASS 10.0 - 27270801
