1057654 | SICK SENSORS | DS35-B15521 Laser Distance Sensor

₹ 30,569.67

₹ 25,906.50 (Excl. Tax)

Get Best Price on WhatsApp

Product Description



Target Natural objects
Resolution 0.1 mm
Repeatability ≥ 0.5 mm 2) 3)
Measurement accuracy Typ. ± 10 mm 4)
Response time 4.5 ms ... 192.5 ms, 4.5 ms / 12.5 ms / 24.5 ms / 48.5 ms / 192.5 ms 5) 6)
Switching frequency 166 Hz/50 Hz/25 Hz/12 Hz/3 Hz 5) 6)
Output time 2 ms ... 64 ms, 2 ms/4 ms/8 ms/16 ms/64 ms 5) 7)
Light source Laser, red 8)
visible red light
Type of light Visible red light
Laser class 1 (IEC 60825-1:2014, EN 60825-1:2014)
Supply voltage UB DC 12 V ... 30 V 1) 2)
Power consumption ≤ 1.7 W 3)
Ripple ≤ 5 Vpp 4)
Initialization time ≤ 500 ms
Warm-up time ≤ 20 min
Indication LEDs
Enclosure rating

IP65

IP67



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1057654

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Measuring range - 50 mm to 12,000 mm (90% remission factor); 50 mm to 5,300 mm (18% reflection factor); 50 mm to 3,100 mm (6% remission factor)

Target - Natural objects

Resolution - 100 µm

Repeatability - ≥ 0.5 mm

Measurement accuracy - Typical ± 10 mm

Response time - 4.5 ms to 192.5 ms (4.5 ms / 12.5 ms / 24.5 ms / 48.5 ms / 192.5 ms)

Switching frequency - 166 Hz / 50 Hz / 25 Hz / 12 Hz / 3 Hz

Output time - 2 ms to 64 ms (2 ms / 4 ms / 8 ms / 16 ms / 64 ms)

Emitted beam - Laser beam

Light source - Red laser

Supply voltage (UB) - DC 12 V to 30 V

Power consumption - ≤ 1.7 W

Ripple - ≤ 5 Vpp

Initialization time - ≤ 500 ms

Warm-up time - ≤ 20 min

Display - LEDs

Enclosure rating - IP65, IP67

Protection class - Class III

Dimensions (W × H × D) - 32 mm × 58.67 mm × 42.7 mm

Housing material - Plastic (ABS/PC)

Window material - Plastic (PMMA)

Weight - 65 g

Not applicable for this product

EU Declaration of Conformity - Yes

UK Declaration of Conformity - Yes

ACMA Declaration of Conformity - Yes

Moroccan Declaration of Conformity - Yes

China RoHS - Yes

ECLASS 5.1.4 - 27270801

ECLASS 6.0 - 27270801

ECLASS 7.0 - 27270801

ECLASS 8.0 - 27270801

ECLASS 9.0 - 27270801
