1047396 | SICK SENSORS | DT50-N1113 Laser Distance Sensor

₹ 41,852.35

₹ 35,468.10 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Target Natural objects
Resolution 1 mm
Repeatability ≥ 2.5 mm 1) 2) 3)
Measurement accuracy ± 10 mm 4)
Response time 20 ms ... 30 ms, 20 ms / 30 ms 3) 5)
Output time ≥ 4 ms 6)
Light source Laser, red
visible red light
Supply voltage UB DC 10 V ... 30 V 1) 2)
Power consumption ≤ 2.1 W 3)
Ripple ≤ 5 Vpp 4)
Initialization time ≤ 250 ms
Warm-up time ≤ 15 min
Indication LC display, 2 x LED
Enclosure rating IP65



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1047396

Original Equipment Manufacturer

SICK SENSORS

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Target - Natural objects

Resolution - 1,000 µm

Repeatability - ≥ 2.5 mm

Measurement accuracy - ± 10 mm

Response time - 20 ms to 30 ms (20 ms / 30 ms)

Output time - ≥ 4 ms

Supply voltage (UB) - DC 10 V to 30 V

Power consumption - ≤ 2.1 W

Ripple - ≤ 5 Vpp

Initialization time - ≤ 250 ms

Warm-up time - ≤ 15 min

Display - LC display, 2 × LED

Enclosure rating - IP65

Dimensions (W × H × D) - 36.1 mm × 62.7 mm × 57.7 mm

Housing material - Metal (zinc diecast)

Window material - Plastic (PMMA)

Weight - 200 g

Not applicable for this product

EU Declaration of Conformity - Yes

UK Declaration of Conformity - Yes

ACMA Declaration of Conformity - Yes

Moroccan Declaration of Conformity - Yes

China RoHS - Yes

China Compulsory Product Certification (CCC) Exempt - Yes

ECLASS 5.1.4 - 27270801

ECLASS 6.0 - 27270801

ECLASS 7.0 - 27270801

ECLASS 8.0 - 27270801

ECLASS 9.0 - 27270801

ECLASS 10.0 - 27270801

ECLASS 11.0 - 27270801

ECLASS 12.0 - 27270916
