1047314 | SICK SENSORS | DT50-P2113 Laser Distance Sensor

₹ 119,819.08

₹ 101,541.60 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Target Natural objects
Resolution 1 mm
Repeatability ≥ 1 mm 1) 2) 3)
Measurement accuracy ± 7 mm 4)
Response time 15 ms ... 80 ms, 15 ms / 30 ms / 80 ms 3) 5)
Output time ≥ 2 ms 6)
Light source Laser, red
visible red light
Type of light Visible red light
Laser class 2 (IEC 60825-1:2014, EN 60825-1:2014) 7)
Supply voltage UB DC 10 V ... 30 V 1)
Power consumption ≤ 2.1 W 2)
Ripple ≤ 5 Vpp 3)
Initialization time ≤ 250 ms
Warm-up time ≤ 15 min
Indication LC display, 2 x LED
Enclosure rating IP65



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1047314

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Target - Natural objects

Resolution - 1,000 µm

Repeatability - ≥ 1 mm

Measurement accuracy - ± 7 mm

Response time - 15 ms to 80 ms (15 ms / 30 ms / 80 ms)

Output time - ≥ 2 ms

Supply voltage (UB) - DC 10 V to 30 V

Power consumption - ≤ 2.1 W

Ripple - ≤ 5 Vpp

Initialization time - ≤ 250 ms

Warm-up time - ≤ 15 min

Display - LC display, 2 × LED

Enclosure rating - IP65

Protection class - Class III

Dimensions (W × H × D) - 36.1 mm × 62.7 mm × 57.7 mm

Housing material - Metal (zinc diecast)

Window material - Plastic (PMMA)

Weight - 200 g

Not applicable for this product

EU Declaration of Conformity - Yes

UK Declaration of Conformity - Yes

ACMA Declaration of Conformity - Yes

Moroccan Declaration of Conformity - Yes

China RoHS - Yes

China Compulsory Product Certification (CCC) Exempt - Yes

cULus Certificate - Yes

ECLASS 5.1.4 - 27270801

ECLASS 6.0 - 27270801

ECLASS 7.0 - 27270801

ECLASS 8.0 - 27270801

ECLASS 9.0 - 27270801

ECLASS 10.0 - 27270801

ECLASS 11.0 - 27270801

ECLASS 12.0 - 27270916

ECLASS 13.0 - 27270916
