6049705 | SICK SENSORS | PBT-AP015AN1SS0ALA0Z Pressure Sensor

₹ 31,272.71

₹ 26,502.30 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Medium Liquid, gaseous
Pressure type Absolute pressure
Pressure unit psi
Measuring range 0 psi ... 15 psi
Process temperature 0 °C ... +80 °C
Maximum ohmic load RA 4 mA ... 20 mA, 2-wire (RA ≤ (L+ - 8 V) / 0.02 A [Ohm]), 0 V ... 10 V, 3-wire (RA > 10 kOhm), 0 V ... 5 V, 3-wire (RA > 5 kOhm)
Output signal 4 mA ... 20 mA, 2-wire
Ambient temperature, operation 0 °C ... +80 °C
Storage temperature –40 °C ... +70 °C
Relative humidity 45 % ... 75 %
Shock load 500 g according to IEC 60068-2-27 (mechanical shock)
Vibration load

10 g according to IEC 60068-2-6 (vibration under resonance)

20 g optional



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

6049705

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Medium - Liquid, gaseous

Pressure Type - Absolute pressure

Pressure Unit - psi

Measuring Range - 0 psi ... 15 psi

Process Temperature - 0 °C ... +80 °C

Maximum Ohmic Load RA - 4 mA ... 20 mA, 2-wire (RA ≤ (L+ - 8 V) / 0.02 A [Ohm]), 0 V ... 10 V, 3-wire (RA > 10 kOhm), 0 V ... 5 V, 3-wire (RA > 5 kOhm)

Output Signal - 4 mA ... 20 mA, 2-wire

Communication Interface - -

Process Connection - ¼'' NPT

Wetted Parts -

Process Connection - 316L stainless steel

Measuring Chamber - Stainless steel 316L

Internal Transmission Fluid - Silicone oil (only with pressure ranges < 0 bar ... 10 bar and ≤ 0 bar abs ... 25 bar abs)

Pressure Port - Standard

Housing Material - Stainless steel

Connection Type - L-connector (DIN EN 175301-803 A)

Supply Voltage - 8 V DC ... 30 V DC 1)

Not applicable for this product

EU Declaration of Conformity - ✔

UK Declaration of Conformity - ✔

China RoHS - ✔

China Compulsory Product Certification (CCC) Exempt - ✔

cULus Certificate - ✔

ECLASS 5.1.4 - 27200614

ECLASS 6.0 - 27200614

ECLASS 7.0 - 27200614

ECLASS 8.0 - 27200614

ECLASS 9.0 - 27200614

ECLASS 10.0 - 27200614

ECLASS 11.0 - 27200614
